| Nombre | Especificaciones Técnicas | Unidad |
| TABLE SIZE | 305 x 1370 | mm |
| LONG TRAVEL | 850 | mm |
| CROSS TRAVEL | 400 | mm |
| VERTICAL TRAVEL | 400 | mm |
| T-SLOT DISTANCE | 65 | mm |
| TABLE LOAD CAPACITY | 300 | kg |
| T-SLOT NO. AND SIZE | 3 x 16 | mm |
| DISTANCE FROM VERTICAL SPINDLE TO TABLE | 0 . 400 | mm |
| DISTANCE FROM HORIZONTAL SPINDLE TO RAM SURFACE | 270 | mm |
| SPINDLE HOLE TAPER | NT40 | |
| SPINDLE TRAVEL | 127 | mm |
| VERTICAL SPINDLE SPEED | 60 , 80-5440 | Hz ; rpm |
| HORIZONTAL SPINDLE SPEED | 40-1300 (12 pasos) | rpm |
| HORIZONTAL SPINDLE MOTOR POWER | 2.2 | kW |
| SPINDLE MOTOR | 3.75 / 5 | kW / HP |
| COOLANT MOTOR POWER | 0.04 | kW |
| HEAD SWIVEL | 90° | |
| HEAD TILTING | 45° | |
| G.W / SET | 1380 | kg |
| STANDARD ACCESSORIES | ||
| 5HP 16 STEPS MILLING HEAD | ||
| SPINDLE QUILL DIAMETER 105MM | ||
| TABLE SIZE 1370×305MM | ||
| TABLE TRAVEL 850×400×400MM | ||
| H&V SPINDLE TAPER ISO40 | ||
| Y&Z AXIS BOX GUIDE WAY | ||
| X AXIS TAIL GUIDE WAY | ||
| X&Y AXIS GUIDE WAY TURCITE-B | ||
| HARDNESS FOR YZ AXIS SURFACE AROUND HRC48 | ||
| XY AXIS ALSGS POWER FEED | ||
| Z AXIS LIFTING MOTOR | ||
| AUTOMATIC LUBRICATING SYSTEM | ||
| SPINDLE PROTECTION | ||
| ALUMINUM CANTILEVER CONTROL PANEL WITH 24V CENTRALIZED CONTROL | ||
| SIEMENS ELECTRIC COMPONENTS | ||
